6000W Pure Sine Wave Inverter

Item No.: TP-6000W-A-1
YIKA 12V 24V 48V DC TO AC 100V 110V120V 220V 230V 240V 50HZ 60HZ 6000 Watt Pure Sine Wave Power Inverter
  • Product Name:Pure Sine Wave Inverter
  • Product Model:TP-6000W-A
  • Product Type:DC TO AC
  • Output Power:6000W
  • Input Voltage:DC12V/DC24V/DC48V
  • Output Voltage:AC100V/AC110V/AC120V/AC220V/AC230V/AC240V
  • More Less
    Description About Us Trade Shows Contact Us Review

    Reliable High Efficiency Inverter 6000W 12V 24V 220V 120V 50HZ 60HZ Power Converter 6000 Watt Pure Sine Wave Power Inverter

    Reliable High Efficiency Inverter 6000W 12V 24V 220V 120V 50HZ 60HZ Power Converter 6000 Watt Pure Sine Wave Power Inverter converts DC power (battery, battery) into alternating current (typically 220V, 50Hz sine wave). It consists of an inverter bridge, control logic and filter circuits. The pure positive sleek inverter is suitable for any inductive load and resistive load. The inductive load includes various equipments with AC motor, refrigerator, washing machine, etc.

    Technical Parameters for 6000W-A Pure Sine Wave Inverter
    Model TP-6000W-12V TP-6000W-24V TP-6000W-48V
    Rated power 6000W
    Peak power 12000W
    Input voltage(Range) DC12V(9-15.5V) DC24V(18-31V) DC48V(38-61V)
    Output voltage(Single) (100VAC/110VAC/120VAC/220VAC/230VAC/240VAC)±5%
    Unload current less than ≤1.2A ≤0.6A ≤0.3A
    Output frequency 50Hz or 60Hz
    Output waveform Pure Sine Wave
    Waveform distortion THD≤3%(Pure resistive Load))
    USB 5V,2.1A /
    Max.efficiency 90%
    Low voltage protection Pre-alarm (alarm off after 1 sound), LED Red light on, voltage contiously reduce and shutdown
    Over voltage protection  Pre-alarm (alarm off after 2 sounds), LED Red light on,  shutdown
    Over load protection Continuous alarm, LED Red light on, shutdown
    Over temperature protection Pre-alarm (alarm off after 3 sounds), tempurature continously rise, LED Red light on, shutdown
    Short circuit protection Perfect protection and no damage the circuit
    Input polarity protection Fuse burn-out
    Low voltage alarm 10.5±0.5V 21±0.5V 42±1V
    Low voltage protection 9.5±0.5V 19±0.5V 38±1V
    Over voltage protection 15.5±0.5V 31±0.5V 61±1V
    Low voltage recover 13±0.5V 24±0.5V 48±1V
    Over voltage recover 14V±0.2V 28V±0.5V 54V±1V
    Working temperature -10°- +50°
    Product Dimension(mm) 505*205*165
    Mounting Size(mm) 475*130
    Product Lable Size(mm)
    Packing(mm) 555*267*210
    Net./gross weight(g) 10000/11700
    QTY/CTN 1 PC
    Meas./CTN(mm) 555*267*210
    Gross weight/CTN(g) 11700
    Warranty 12Months
    DC Cable(mm²)
    Spare Fuse
    Cooling method Intelligent air cooling
    Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product.
